Product Collection

4th Generation Intel® Core™ i5 Processors

Code Name

Products formerly Haswell

Vertical Segment

Mobile

Processor Number

i5-4210M

Lithography

22 nm

CPU Specifications

Total Cores

2

Total Threads

4

Max Turbo Frequency

3.20 GHz

Intel® Turbo Boost Technology 2.0 Frequency‡

3.20 GHz

Processor Base Frequency

2.60 GHz

Cache

3 MB Intel® Smart Cache

Bus Speed

5 GT/s

TDP

37 W

Supplemental Information

Marketing Status

Discontinued

Launch Date

Q2'14

Servicing Status

End of Servicing Lifetime

End of Servicing Updates Date

Wednesday, June 30, 2021

Embedded Options Available

No

Datasheet

View now

Memory Specifications

Max Memory Size (dependent on memory type)

32 GB

Memory Types

DDR3L 1333/1600

Max # of Memory Channels

2

Max Memory Bandwidth

25.6 GB/s

ECC Memory Supported ‡

No

GPU Specifications

GPU Name‡

Intel® HD Graphics 4600

Graphics Base Frequency

400 MHz

Graphics Max Dynamic Frequency

1.15 GHz

Graphics Video Max Memory

2 GB

Graphics Output

eDP/DP/HDMI

Max Resolution (HDMI)‡

3840x2160@60Hz

Max Resolution (DP)‡

3840x2160@60Hz

Max Resolution (VGA)‡

2880x1800@60Hz

DirectX* Support

11.2/12

OpenGL* Support

4.3

Intel® Quick Sync Video

Yes

Intel® InTru™ 3D Technology

Yes

Intel® Clear Video HD Technology

Yes

# of Displays Supported ‡

3

Device ID

0x416

Expansion Options

PCI Express Revision

3

PCI Express Configurations ‡

1x16 or 2x8 or 1x8 2x4

Max # of PCI Express Lanes

16

Package Specifications

Sockets Supported

FCPGA946

Max CPU Configuration

1

TJUNCTION

100°C

Package Size

37.5mm x 37.5mm x 4.7mm

Advanced Technologies

Intel® Turbo Boost Technology ‡

2.0

Intel® Hyper-Threading Technology ‡

Yes

Intel® Transactional Synchronization Extensions

No

Intel® 64 ‡

Yes

Instruction Set

64-bit

Instruction Set Extensions

Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Enhanced Intel SpeedStep® Technology

Yes

Thermal Monitoring Technologies

Yes

Intel® Identity Protection Technology ‡

Yes

Security & Reliability

Intel® Secure Key

Yes

Intel® AES New Instructions

Yes

Intel® Trusted Execution Technology ‡

No

Execute Disable Bit ‡

Yes

Anti-Theft Technology

Yes

Intel® Virtualization Technology (VT-x) ‡

Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡

No

Intel® VT-x with Extended Page Tables (EPT) ‡

Yes
