W pełni sprawny w doskonałym stanie wizualnym i technicznym

Connections

• Number of inputs:

  • Line In: 100 mV, 50 kOhm

Aux: 100 mV, 50 kOhm Line In DIN: 0.3 mV, 50 kOhm

• Microphone: 0.25 mV, 600 Ohm - 10 kOhm

• Number of outputs:

  • Line Out: 410 mV, 50 kOhm

Line Out DIN: 410 mV, 50 kOhm

• Headphones: 1 mW, 8 Ohm

Technical Data

• Audio heads: 2

• Motor: 1x DC Servo

• Synchronization fluctuations: 0,09 % WMRS

• Tape types: Normal, Chrome

• Frequency response:

  • Normal: 40 - 12'000 Hz

  • Chrome: 40 - 15'000 Hz

• Distortion factor: 2

• Signal to Noise Ratio:

  • Dolby Off: 57 dB

  • Dolby On: 67 dB (Cr)

• Auto Reverse: No

• Title Search: No

• Dolby: B

• MPX Filter: No

• Fader: Yes

• Pitch control: No

• Channel separation: > 30 dB at 1 kHz

• Crosstalk attenuation: > 70 dB

• Cancellation attenuation: > 70 dB

• Premagnetization frequency: 85 kHz

• Rewind time: 90 seconds for C-60
